| System | |
|---|---|
| OS | Windows® 10 Enterprise 2016 LTSB |
| CPU | Intel ® Celeron ® Processor N3160 |
| RAM | 4GB, 1 x DDR3L (up to 8GB) - 1600Hz (1,35V) |
| HDD | 64 GB SSD, expandable |
| Ports | 4 x COM ports RJ-45 connectors (2 ports with power: 5V=green LED/12V=yellow LED, enabled by BIOS) |
| USB | 6 x USB (2 x USB 3.0 - 4 x USB 2.0) |
| LAN | 1 x RJ-45 (10/100/1000Mbps Giga LAN) |
| Audio | 1 x combo (Mic & Line-out) |
| Drawer | 1 x RJ-11 (12V/24V) |
| DC Jack | 1 |
| Second Display | 1 x HDMI (12V power by DC-jack, enabled in BIOS) |
| Physical parameters | |
|---|---|
| Modular / one-piece | All in one |
| Screen | 18.5" LED LCD |
| Resolution | 1366 x 768 |
| Power | DC 90W, 19V, 4,74A |
| Operating temperature | 0°C to +60°C |
| Operating humidity | 20% to 80% RH non-condensing |
| Audio | 2 x 2W |
| Wall mount | 70mm x 70mm & 100mm x 100mm VESA mounting hole for panel PC type |
| Weight | 6,9kg |
| Dimensions | 470 x 200 x 350 mm |
| Approvals | FCC, CE |
| Display | |
|---|---|
| Type | Projected Capacitive with 10 touch points |
| Brightness | 300 cd/m² |
| Options | |
|---|---|
| Customer display | 2x20 VFD or 10.1 , 14" or 15" Second LCD Display with or without touch (option) |
| i-button | Option |
| Fingerprint | 1 (USB) (option) |
| MSR | 3 Tracks MSR USB (option) |
